Agility Series mSATA SSD

STARCAND SOLUTION Agility Series mSATA SSD

Features

  • Advanced wear leveling
  • TRIM function support
  • Static Data Refresh and Idle Clean F/W algorithm
  • Firmware live update

DESCRIPTION

STARCAND SOLUTIONS introduces the Agility Series, as A – Series, mSATA SSDs for outstanding performance especially in compact embedded environments. As the size of a small pen drive, STARCAND A - Series mSATA SSDs offer up to 512 GB capacity with the same performance and efficiency like standard SATA. They are designed to fit in systems with space constraints and high-storage performance requirements such as embedded and networking applications.

Two mounting holes keep the mSATA module securely installed, protecting it from shock and vibration. STARCAND SOLUTIONS mSATA SSDs are available in industrial temperature ratings for trustworthy performance in extreme operation environments. With the option of advanced power loss protection (PLP) available in the mSATA form factor, It is specially designed to prevent data corruption and storage device damage when power glitches, losses and failures occur.

These compact SSDs provide outstanding performance and high capacity, making them perfect choices for small systems installed in limited spaces. The SATA III interface allow quick and reliable integration into SATA-based systems. Along with unique STARCAND’s quality control ensuring endurance for long years use, the A - Series mSATA SSDs are the perfect choices for slim clients, BOX PC and compact size commercial PC systems.

Specification

Storage Size32GB – 512GB
Flash Type3D TLC
Dimensions50.8x29.85x3.5
Interface22 Pin SATAIII 6Gb/s
Seq Read Performance560/MBs
Seq. Write Performance420/MBs
Standard Operating Temperature0°C to 70°C
Industrial Operating Temperature-40°C to 85°C
Operating Humidity5%-95% RH non-condensing
Reliability MTBF>2,000,000 hours

PRODUCT SERIES

Technologies & Add-On Services

  • S.M.A.R.T.
  • Advanced Wear Leveling
  • Auto Refresh
  • TLC
  • MLC, pSLC
  • SLC
  • Wide Temperature
  • Power Loss Protection
  • Write-Protect or Read Only
  • Opal / AES
  • Quick Erase
  • Conformal Coating

Agility Series (A-Series)

Utility Series (U-Series)
